LACED WHEEL ASSEMBLIES

LACED WHEEL ASSEMBLIES
  • LACED WHEEL ASSEMBLIES
  • All wheels use a center metal valve stem tube except the 16" x 3.5" wheels, which use a side metal valve stem
  • Applications for most popular models; charts below are arranged by wheel rim size and then by application
  • Bearings, seals and center spacer are included
  • Billet chromed custom aluminum hubs
  • Chrome-plated steel rims in 40-, 60- or 80-spoke styles
  • DOT-approved and trued to less than .005" runout
  • High-quality American-made tube-type wheel assemblies
  • Made in the U.S.A.
  • Polished stainless steel spokes with custom smooth nipples
Wheel Assembly

Wheel Assembly

Part #DescriptionSug. Retail Price
0203-0040Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15"$869.95
0203-0041Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15" Single Disc$869.95
0203-0042Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15" Single Disc$869.95
0203-0043Laced Wheel Assembly Front Wheel 80 Spoke 16" X 3.5"$829.95
0203-0046Laced Wheel Assembly Front Wheel 80 Spoke 18" X 3.5"$889.95
0203-004719X2.15-80D/DFRT00-03DYNA$866.95
0203-0048Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15"$819.95
0203-0049Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15" Single Disc$819.95
0203-0050Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15" Single Disc$819.95
0203-0051Laced Wheel Assembly Front Wheel 60 Spoke 16" X 3.5"$819.95
0203-0054Laced Wheel Assembly Front Wheel 60 Spoke 18" X 3.5"$869.95
0203-0055Laced Wheel Assembly Front Wheel 60 Spoke 18" X 3.5"$869.95
0203-005619X2.15-60S/D FR 00-03FXD$790.95
0203-0057Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15"$799.95
0203-0058Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15" Single Disc$799.95
0203-0059Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15" Single Disc$799.95
0203-0060Laced Wheel Assembly Front Wheel 40 Spoke 16" X 3.5"$769.95
0203-0063Laced Wheel Assembly Front Wheel 40 Spoke 18" X 3.5"$819.95
0203-0064Laced Wheel Assembly Front Wheel 40 Spoke 18" X 3.5"$819.95
0203-006519X2.15-40S/D FRT.00-03FX$790.95
0203-0066Laced Wheel Assembly Front Wheel 40 Spoke 16" X 3.5"$769.95
0203-0067Laced Wheel Assembly Front Wheel 60 Spoke 16" X 3.5"$819.95
0203-0068Laced Wheel Assembly Front Wheel 80 Spoke 16" X 3.5"$829.95
0203-0069Laced Wheel Assembly Front Wheel 40 Spoke 16" X 3.5"$769.95
0203-0070Laced Wheel Assembly Front Wheel 60 Spoke 16" X 3.5"$819.95
0203-0071Laced Wheel Assembly Front Wheel 80 Spoke 16" X 3.5"$829.95
0203-0081Laced Wheel Assembly Front Wheel 40 Spoke 19" X 2.15" Single/Dual Disc$799.95
0203-0082Laced Wheel Assembly Front Wheel 60 Spoke 19" X 2.15" Single/Dual Disc$829.95
0203-0083Laced Wheel Assembly Front Wheel 80 Spoke 19" X 2.15" Single/Dual Disc$869.95
0203-0084Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15"$799.95
0203-0085Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15"$819.95
0203-0086Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15"$869.95
0203-008721X2.15-60 96-99FXSTS F/W$790.95
0203-008821X2.15-80 96-99FXSTS F/W$847.95
0203-0089Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15" Single/Dual Disc$799.95
0203-0090Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15" Single/Dual Disc$819.95
0203-0091Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15" Single/Dual Disc$869.95
0203-009221X2.15-40 80-3WG STL WHL$723.95
0203-009321X2.15-80 80-3WG STL WHL$847.95
0203-009421X2.15"40 SPK 88-95FXSTS$533.95
0203-009521X2.15"60 SPK 88-95FXSTS$399.95
0203-009621X2.15"80 SPK 88-95FXSTS$399.95
0203-0334Laced Wheel Assembly Front Wheel 40 Spoke 16" X 3.5"$769.95
0203-0336Laced Wheel Assembly Front Wheel 60 Spoke 16" X 3.5"$819.95
0203-0337Laced Wheel Assembly Front Wheel 80 Spoke 16" X 3.5"$829.95
0203-0376Laced Wheel Assembly Front Wheel 40 Spoke 17" X 3.5"$819.95
0203-0378Laced Wheel Assembly Front Wheel 60 Spoke 17" X 3.5"$869.95
0203-0379Laced Wheel Assembly Front Wheel 80 Spoke 17" X 3.5"$929.95
0203-0380Laced Wheel Assembly Front Wheel 40 Spoke 18" X 3.5"$819.95
0203-0382Laced Wheel Assembly Front Wheel 60 Spoke 18" X 3.5"$869.95
0203-0383Laced Wheel Assembly Front Wheel 80 Spoke 18" X 3.5"$889.95
0203-0384Laced Wheel Assembly Front Wheel 40 Spoke 21" X 3.5"$829.95
0203-0386Laced Wheel Assembly Front Wheel 60 Spoke 21" X 3.5"$849.95
0203-0387Laced Wheel Assembly Front Wheel 80 Spoke 21" X 3.5"$889.95
0203-0388F WHEEL 19X2.15 60SP FXCW$790.95
0203-0389F WHEEL 19X2.15 80SP FXCW$847.95
0203-0390Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15"$799.95
0203-0392Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15"$829.95
0203-0393Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15"$869.95
0203-0395Laced Wheel Assembly Front Wheel 80 Spoke 21" X 2.15"$869.95
0203-0396Laced Wheel Assembly Front Wheel 80 Spoke 19" X 2.15"$869.95
0203-0397Laced Wheel Assembly Front Wheel 60 Spoke 21" X 2.15"$819.95
0203-0398Laced Wheel Assembly Front Wheel 60 Spoke 19" X 2.15"$829.95
0203-0399Laced Wheel Assembly Front Wheel 40 Spoke 21" X 2.15"$799.95
0203-0400Laced Wheel Assembly Front Wheel 40 Spoke 19" X 2.15"$799.95
0203-0404Laced Wheel Assembly Front Wheel 40 Spoke 21" X 3.5" ABS$909.95
0203-0406Laced Wheel Assembly Front Wheel 60 Spoke 21" X 3.5" ABS$929.95
0203-0407Laced Wheel Assembly Front Wheel 80 Spoke 21" X 3.5" ABS$969.95
Wheel Assembly

Wheel Assembly

Part #DescriptionSug. Retail Price
0204-0053Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0055Laced Wheel Assembly Rear Wheel 80 Spoke 18" X 3.5"$889.95
0204-0056Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0057Laced Wheel Assembly Rear Wheel 60 Spoke 18" X 3.5"$869.95
0204-0059Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0061Laced Wheel Assembly Rear Wheel 40 Spoke 18" X 3.5"$819.95
0204-0067Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0068Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0069Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0070Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0071Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0072Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-007318X3.5-40FX/XL RR STL WHL$714.95
0204-007418X3.5-60FX/XL RR STL WHL$752.95
0204-007518X3.5-80FX/XL RR STL WHL$800.95
0204-0079Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0080Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0081Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0224Laced Wheel Assembly Rear Wheel 40 Spoke 18" X 5.5"$869.95
0204-0225Laced Wheel Assembly Rear Wheel 60 Spoke 18" X 5.5"$909.95
0204-0226Laced Wheel Assembly Rear Wheel 80 Spoke 18" X 5.5"$929.95
0204-0303Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0305Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0306Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0307Laced Wheel Assembly Rear Wheel 40 Spoke 18" X 3.5"$819.95
0204-0309Laced Wheel Assembly Rear Wheel 60 Spoke 18" X 3.5"$869.95
0204-0310Laced Wheel Assembly Rear Wheel 80 Spoke 18" X 3.5"$889.95
0204-0338Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$849.95
0204-0340Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$889.95
0204-0341Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$929.95
0204-0342Laced Wheel Assembly Rear Wheel 40 Spoke 18" X 5.5"$869.95
0204-0344Laced Wheel Assembly Rear Wheel 60 Spoke 18" X 5.5"$909.95
0204-0345Laced Wheel Assembly Rear Wheel 80 Spoke 18" X 5.5"$929.95
0204-0346R WHEEL 18X8.5 60SP FXCW$971.95
0204-0347R WHEEL 18X8.5 80SP FXCW$1,009.95
0204-0348Laced Wheel Assembly Rear Wheel 40 Spoke 17" X 6"$849.95
0204-0350Laced Wheel Assembly Rear Wheel 60 Spoke 17" X 6"$889.95
0204-0351Laced Wheel Assembly Rear Wheel 80 Spoke 17" X 6"$929.95
0204-0355Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0356Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0357Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0358Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0359Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0360Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0361Laced Wheel Assembly Rear Wheel 40 Spoke 16" X 3.5"$769.95
0204-0362Laced Wheel Assembly Rear Wheel 60 Spoke 16" X 3.5"$819.95
0204-0363Laced Wheel Assembly Rear Wheel 80 Spoke 16" X 3.5"$829.95
0204-0364Laced Wheel Assembly Rear Wheel 40 Spoke 18" X 5.5" ABS$929.95
0204-0366Laced Wheel Assembly Rear Wheel 60 Spoke 18" X 5.5" ABS$999.95
0204-0367Laced Wheel Assembly Rear Wheel 80 Spoke 18" X 5.5" ABS$999.95
